RD-10 Drum Vacuum Plasma Cleaner

A compact rotary vacuum plasma cleaner with a 360° rotating reaction chamber for uniform, stable surface cleaning and activation of powders, particles and small irregular parts to improve adhesion.

360° Rotating Drum for Uniform Processing
Compact, Stable Design for Small-Batch Production
Enhances Surface Cleanliness and Adhesion

Get A Quote Tech Specs

Tech Specs

Product Name	Rotary Drum Vacuum Plasma Cleaner
Model	RD-10
Control System	PLC + Touchscreen
Plasma Power Frequency	13.56 MHz
Power Supply	AC 220V (±10V)
Plasma Generator Power	100 W (adjustable)
Gas Lines	2 gas channels with rotameters
Process Control	Automatic and Manual modes
Chamber Size (mm)	Ø210 × 310 mm
Vacuum Reaction Chamber Size (mm)	Ø160 × 230 mm
Overall Dimensions (mm)	700 × 640 × 475 (L × W × H)
Reaction Volume	5 L
Motor Speed Range	1–30 rpm
Vacuum Level	10–30 Pa

Key Features

360° Rotational Uniform Surface Processing

Integrated rotating vacuum drum provides full 360° exposure ensuring uniform plasma treatment across powders, particles and irregular parts for consistent surface activation and cleaning.
Compact Design for Small-Batch Production

Space-efficient footprint designed for lab and small-scale manufacturing applications, offering stable performance and easy integration into existing production lines for prototype and pilot runs.
Adjustable Plasma Power And Frequency

100 W adjustable plasma generator operating at 13.56 MHz enables fine control over treatment intensity, allowing optimization for different materials and process requirements.
Vacuum Processing For Sensitive Materials

Low-pressure operation (10–30 Pa) allows safe plasma cleaning and activation of delicate components and powders while minimizing thermal and mechanical stress during processing.
Dual Gas Flow Control With Rotameters

Two independent gas channels with rotameters enable precise gas composition and flow control to tailor plasma chemistries and improve adhesion or surface modification outcomes.
PLC Touchscreen Automation and Monitoring

User-friendly PLC and touchscreen interface supports automated or manual process modes, recipe storage and repeatable cycles for consistent production and simplified operator operation.

Plasma Cleaning Process

Plasma Generation

Process gas is energized and converted into a reactive plasma containing ions, electrons, and radicals.
Plasma–Surface Interaction

High-energy plasma species reach the material surface and interact with contaminants at the molecular level.
Chemical Reaction

Reactive ions and radicals break down organic residues and surface contaminants through controlled chemical reactions.
Volatilization

The reaction products are converted into volatile compounds and enter the gas phase.
Removal from Surface

Gaseous by-products desorb from the surface and are evacuated, leaving a clean, activated material surface.
